Tiger 800 Problematic

Discussion in 'Tiger / Explorer' started by Chris Ryder, May 14, 2019.

  1. This site uses cookies. By continuing to use this site, you are agreeing to our use of cookies. Learn More.
  1. Chris Ryder

    Chris Ryder Member

    May 10, 2019
    19
    8
    Blackpool
    The bikes been fine all winter , only gone on shortish rides , when
    Think I will invest in a new one , believe I've still got the original one . 60, 000 + miles !

    • Like Like x 1
    • Agree Agree x 1
  2. Chris Ryder

    Chris Ryder Member

    May 10, 2019
    19
    8
    Blackpool
    Current on is a YUASA YTX16- BS . I get one for £ 50 00 .

    • Like Like x 1
    • Agree Agree x 1
  3. capt

    capt Elite Member

    May 8, 2016
    3,052
    750
    western Australia
    A poor battery can draw most of the charging systems output, and not enough voltage is there to run the electronics , ECU won't run at proper speed/efficiency if voltage is down, also the fuel pump and injection might not work to it's best ! My sprint slowly became a little more reluctant to start , and top performance and responsiveness went down. Didn't fully appreciate how much until I did a battery replacement .

    • Like Like x 1
    • Useful Useful x 1
    • Agree Agree x 1
  4. Chris Ryder

    Chris Ryder Member

    May 10, 2019
    19
    8
    Blackpool
    Thanks man , I think that will be the next step . New Battery . Currently shows 12 . 63 V when not been used for a da.y or two ..

    • Agree Agree x 2
  5. joe mc donald

    Dec 26, 2014
    13,874
    1,000
    slough / burnham
    Chris Ryder
    Also if only short journeys the battery doesn't do to well with that either.
    Ride Safe
    Joe.

    • Agree Agree x 2
  6. Chris Ryder

    Chris Ryder Member

    May 10, 2019
    19
    8
    Blackpool
    Hi Joe , I've had the battery tested this morning , is charging O K and holding its charge ! I was advised that it may be the solenoid, or the starter motor !!

    • Agree Agree x 1
  7. freck

    freck Elite Member

    May 4, 2017
    1,719
    750
    Preston, Lancs, UK
    That’s funny, I thought I’d said that a few days ago :p

  8. Chris Ryder

    Chris Ryder Member

    May 10, 2019
    19
    8
    Blackpool
    You did indeed . I'm gonna whip the starter out soon . Found the solenoid , it's right under the battery . Earth lead is secure too ...did 40 miles today without a hitch ?

    • Like Like x 1
  9. Eldon

    Eldon Elite Member

    Nov 14, 2018
    4,061
    800
    North Yorkshire
    Earth lead being secure is one thing .......... but you need to be doing a continuity (ohms) test at various points whilst turning the steering and waggling wires.

    • Like Like x 1
  10. Chris Ryder

    Chris Ryder Member

    May 10, 2019
    19
    8
    Blackpool
    #30 Chris Ryder, May 17, 2019
    Last edited: May 17, 2019
    Your getting far too techy for me now !

  11. Sprinter

    Sprinter Kinigit

    Aug 17, 2014
    6,026
    1,000
    uk

    Hes right too.

    • Thanks Thanks x 1
  12. Eldon

    Eldon Elite Member

    Nov 14, 2018
    4,061
    800
    North Yorkshire
    Right Chris a quick (Not comprehensive) learning session to point you in the right direction;

    Buy a basic multimeter, very cheap, put the setting on ohms. Place one probe, say black one (to avoid confusion) directly onto battery negative It helps if the probes have removable crocodile clips so you can connect that and it will look after itself.
    Probe the other earth points, starter motor bolts etc. with the other probe. Meter should read as near to zero as possible.
    The continuity "buzzer" setting will give you a quick idea but an ohms value is more indicative.

    • Useful Useful x 1
  13. Chris Ryder

    Chris Ryder Member

    May 10, 2019
    19
    8
    Blackpool
    The saga continues . I dont think the starter motor is a serviceable unit . So difficult to get to . Got to remove throttle body assembly , something I dont realy want to tackle . So dont know what to do next . ?

  14. freck

    freck Elite Member

    May 4, 2017
    1,719
    750
    Preston, Lancs, UK
    Have a look at the starter solenoid if you can get to it. It’s more likely to be that than the starter.
    Make sure the electrical connections are tight and not corroded on both.

  15. Sprinter

    Sprinter Kinigit

    Aug 17, 2014
    6,026
    1,000
    uk
    Now the new battery has fixed the slow turn over. It could be back to the Ignition coil????

  16. Chris Ryder

    Chris Ryder Member

    May 10, 2019
    19
    8
    Blackpool
    Well , looks its fooked . Bike wont start at all . 12 . 65 v in battery . Sluggish turn over , do realy think the starter motor is at fault . Dont want to spend any more money on this bike so I may just scrap it and cut my losses !


  17. freck

    freck Elite Member

    May 4, 2017
    1,719
    750
    Preston, Lancs, UK
    Scrap it! :eek: I’ll give you £100 for it :p

    • Agree Agree x 1
  18. Sprinter

    Sprinter Kinigit

    Aug 17, 2014
    6,026
    1,000
    uk
    Very worst case Spragclutch 100 pounds.

  19. freck

    freck Elite Member

    May 4, 2017
    1,719
    750
    Preston, Lancs, UK
    Plus the labour cost o_O

  20. Sprinter

    Sprinter Kinigit

    Aug 17, 2014
    6,026
    1,000
    uk
    Just a manual, are you near any members?
