SE baffle removal

I used the same hole saw to cut thru the second plate, you don't need the dowel to centre the drill as the hole you have just cut will keep the hole saw "on target". You can remove the drill bit and fit a longer steel rod to the hole saw using the grub screw. I downloaded an app to measure db level, after removing first baffle it was only 2db louder, after second baffle it was 5db louder, with 30 mm hole in third baffle it was 10 db louder but then became much deeper, and throatier. I only drilled out the rest as I wanted TTP tune 3 and that is for straight thru (ish) pipes. I had already removed AI and air box baffle..
If you want to remove everything I have pics of all the crap that came out and some tips for removing it. Honestly it has been the best mod I have done to the bike. With the tune loaded it pulled so well I have now fit 19t sprocket, which for the Monet is another " no brained" mod.



CANS CANS CANS Jez!!



@ DD, I also happen to have a set of laced America wheels which Im going to fit 17" rims to which I can send you pics if you need?



Hi Steve let me know how the exhaust was on a longer ride. I've returned the Classic sport exhausts & awaiting their verdict about a refund through Ebay. In the meantime i'm collecting a 44mm hole cutter from Screwfix & will attempt to debaffle soon. If you feel there is anything i should know beforehand, please inform asap. Thanx Phil.



Was he a big chimp???



Thanx for update, in that last picture is that how it looks now after you have removed the 2nd wall & why did you do it? I presume you have still left the SAI system in place.



Ok just checking as i'm about to do it, roughly how long should it take to drill out as i've got work later ?



Hi Steve, well i've copied you & removed the baffles but used some 3/4" dowel instead of a branch. Just for some cosmetic difference i've painted the 2nd wall in silver heatproof paint like your 1st picture. However i'm still puzzled by your last pic, as it seems to show you have cut away the second wall, either by accident or design, & if so why?
The sound is improved on tick over & revs but had no time to test on the road due to work.



When you did the 1st cut as mine is now, did the 2nd cut make any difference to the running of the bike? I realise it will be louder still, but without the SAI removed i thought it might pop & bang on the over run. Soz to go on about it but wanted to know if i can put my drill away yet lol.



Many thanx going out now to local bike meet so will see & hear for myself in Stage 1 Tune lol



Typical just set off & it hammered it down. Thought sod it & enjoyed the new music from my exhausts. Much better all round but could hear popping on closed throttle. Strangely it seemed deeper & louder when fully warmed up. A longer ride is needed before a decision on drilling out the 2nd wall, as i think that would require the SAI system to be removed to cure the impending increased popping.
Thanx to all for help & comments as this modification is both cheap & a success!



Been on a 110 mile run out today & can safely say no problems with performance or sound. The overun popping is now more of a cackle, with a deeper tone/loudness of the exhaust. If anything the modification has improved the bike with a speed of 105mph (on a closed road obviously) reached easily. I would be interested to hear what the top speed is claimed on my model of bike. Only the baffle has been removed so far & the SAI is still in place. Btw i received a full refund on my returned Classic sports megaphone exhausts so win win !
