Hi I live in Wiltshire and ride a 2003 T100 ( With Golden Jubilee kit ), as per my post somewhere on the forum, I decided to do the 1200 miles service ( I had several bikes and rode the BSa's more than the Triumph hence the low mileage) the valve clearances were outside the tolerances so when I lifted the exhaust camshaft a locating dowel fell into the engine, tried a magnet, also removed the sump and tried to blow it through with compressed air, no luck, so where do I go next? will the crankcase split without removing the clutch? how easy is it to remove the engine and is it going to be too heavy to tip upside down to try and shake the dowel loose?
How about taping a piece of hose air tight to you hoover tool? dont run it for long cos it will heat up quick. Just a thought.
I have decided to remove the screen, mirrors and side panels along with the battery, and after removing the valve caps (marking the position on a compartment box) and with the help of a couple of friends turning the bike upside down to see if offending item drops out, will keep you posted
Wrap the duct tape around the hoses to produce an air tight seal. Then use the narrow hose to search the engine. Theoretically you could use an even narrower hose. This is an idea, a thought.
Welcome to the Asylum you should fit right in. To keep the inmates happy we will need photos. Hope it's black Tucker
Sorry not black, so dull, prefer the shine of Chrome and alloy. not keen on photos, at nearly 69 it gets difficult for me to work out how to do technical computer stuff,
Sorry not black, so dull, prefer the shine of Chrome and alloy. not keen on photos, at nearly 69 it gets difficult for me to work out how to do technical computer stuff,
Well after removing the screen mirrors and side panels, putting a blanket down and two foam dog beds and a clean sheet, a friend and myself turned the bike upside down, nothing dropped out, using the back wheel we turned the engine backwards then forward to the original position, still nothing dropped out. I begin to wonder if it did drop into the engine, another search of the area even sweeping with a large magnet revealed nothing,so I just cannot take a chance on ignoring the situation and wrecking the engine, a question was asked to me , how many dowels are there 12 or 11 and should there be one missing to aid oil drainage?. Has anyone taken a bonneville engine out? is it an easy job? I think providing that Blade in Swindon will take on the job, I may take the engine or even the whole bike with all the removed bits for them to strip it down inspect it and rebuild the bike, after all I should be able to save enough from my pension in 12 months to pay the bill, or should I try this new crowd funding lark?
Hi & Welcome. I also dropped a small screw a couple of days ago & if I hadn't just happened to see where it went I'd never have believed where it finished up, & the distance it travelled - so maybe a wider sweep?
Dropped a rubber washer today Looked and couldnt find it, then found it sitting on the loom not 20mm from where I had it.
Have you engaged gear and, plugs out, turned the engine over with the rear wheel? If you have a dowel in any mechanical area it will either dislodge or lock up the transmission or valve gear.
The dowel dropped into the engine, I had only lifted the camshaft up about an inch, two cam out of one cap and both dropped into the engine casing next to the cam chain, I managed to get one out but not the other, yes I have now turned the engine over several times nothing has jammed or dropped out, but the bike is still upside down, I am waiting for help to turn it back up, then I will turn it over again and see if anything drops. As an extra measure I did sweep the area with a magnet, however I had a clean blue tarpaulin on the ground so really would have no problem seeing anything I dropped.
Well having spent two days making the dumping ground that used to be my BSA workshop into a workshop again, the Triumph has pride of place with the engine now out and on the bench for reassembly. Once I had the engine out of the frame and on the floor, I tipped it onto its rear engine mounts and shook the engine, I then turned it upside down and Bingo out dropped the missing locating dowel, so once I have worked out what shims I require for the valve clearances I will order all the shims, gaskets, o rings and copper washers I need and reassemble it, so should be good to ride in a week or so.
Very well done Richard, you sound like a useful bloke to have around The best of luck with the future work on your bike.
