Scrambler Running Usb Cable To Handlebars?

Discussion in 'Thruxton, Scrambler & Trident' started by RebelHawk, Apr 13, 2020.

  1. RebelHawk

    RebelHawk Well-Known Member

    Mar 1, 2020
    344
    53
    SC, USA
    Has anyone run a USB cable from the charge point under the seat up to the handle bars? Did you find a weather resistant cable or was that a concern? Did you modify the box under the seat to prevent pinching of the cable when shutting the lid? I was thinking about running one up to my where I have my phone mounted to keep it charged on longer rides (when we're allowed to go out again anyway).


    • Like Like x 2
  2. Shaun64

    Shaun64 Senior Member

    Feb 23, 2020
    653
    243
    England
    I ran a cable on my street triple from usb point to run my sat Nav and it’s worked fine , cable was £5 ish off eBay, triumph do a usb to fit the scrambler 1200 on the top yoke £30 ish.

    • Agree Agree x 1
  3. Carl556

    Carl556 Senior Member

    Nov 13, 2019
    269
    113
    Durham Uk
    I ran a long iPhone cable up to my handle bars on my speed twin. Just went under the fuel tank and then a few cable ties to keep it neat. Not had any problems so far running it in rain and washing the bike touch wood !

    • Like Like x 1
    • Agree Agree x 1
  4. Repooh

    Repooh Rarely Satisfied

    Jan 5, 2018
    1,434
    1,000
    Stabby Town
    I had the aux socket fitted, it sits next to steering lock and in headlamp bowl is a connector specifically for it. Always on. Socket £25 i use a Hella to USB adapter

    • Like Like x 1
    • Agree Agree x 1
  5. hagnbike

    hagnbike New Member

    Aug 28, 2025
    0
    1
    Germany
    I had the aux socket installed on the 2021 model. Due to unpleasent events I'm now on a 2025 model, which doesn't come with keyless go (which I like!). There's also no aux socket anymore. At least not near the handlebars. So this topic becomes relevant again.

    I don't like these clunky usb ports that one can mount to the handlebar. Are there options thst look more integrated / hidden?

    • Agree Agree x 1
  6. Wintersdark

    Wintersdark New Member

    Oct 24, 2024
    12
    3
    Alberta, Canada
    I just ran a longish cable up from the socket under the seat (in the "phone compartment" that nobody is ever going to use for that purpose) under the tank and up at the handlebars. I cut a small hole in the side of that phone compartment to route the cable out.

    I was attaching to a wireless charging head on my Quadlock phone mount, so I just added some dielectric grease around the outside of the connector to ensure a waterproof connection, and that's worked perfectly for over a year on my '24, about 10k miles and a full winter of riding.

    • Agree Agree x 1
  7. johne

    johne Standing on the shoulders of dwarves.

    Jan 16, 2020
    2,464
    1,000
    Where the Wolds meet the sea

    I'm planning to do a similar exercise on my Street Triple. The USB socket is under the tail hump and you can just about squeeze a phone in there, but I have an Ultimateaddons bracket on the handlebars (similar to Quadlock), so I've got a long cable ready to use, I've just got to take the fuel tank off and route it up to the bars. Mebbe a winter job now? :idea:

    • Like Like x 1
