Hi And Jack Up My Rear End

Discussion in 'Triumph General Discussion' started by Mick the marshman, Jan 4, 2022.

  1. Mick the marshman

    Mick the marshman New Member

    Nov 11, 2021
    4
    3
    Romney marsh kent
    #1 Mick the marshman, Jan 4, 2022
    hi from a newbie and my first post.
    I've just purchased a 1994 900 sprint to play around with, I am interested in jacking up the rear end, so I am after some longer suspension links (dog bones), does anyone know if another triumph model will fit and what height it gives or are there any aftermarket item on the market I did find a German firm that advertises them, but apparently they don't fit my year.
    any help is much appreciated.
    cheers from wet and cold Romney Marsh Kent .
    Mick the Marshman.

    • Like Like x 1
    • Agree Agree x 1
  2. Octoberon

    Octoberon Crème de la Crème

    Jul 2, 2020
    2,250
    1,000
    Peak District, Yorkshire
    #2 Octoberon, Jan 4, 2022
    Welcome to the forum, Mick. Are you planning to raise the front of the bike as well? If the rear is raised on its own won't it have an effect on the geometry and so the handling?

    • Agree Agree x 1
  3. Mick the marshman

    Mick the marshman New Member

    Nov 11, 2021
    4
    3
    Romney marsh kent
    #3 Mick the marshman, Jan 4, 2022
    Thanks for the welcome. Yes I have raised the front by replacing the top yoke to conventual bar mounts this gave me the difference in the handle bar original mount thickness around 25/30mm i can lower the forks as required once I jack the rear end .

    • Useful Useful x 1
    • Agree Agree x 1
  4. Octoberon

    Octoberon Crème de la Crème

    Jul 2, 2020
    2,250
    1,000
    Peak District, Yorkshire
    #4 Octoberon, Jan 4, 2022
    Sounds like you know what you're doing. :)

    • Agree Agree x 1
  5. Johnjo

    Johnjo Senior Member

    May 29, 2017
    548
    243
    Birmingham
    #5 Johnjo, Jan 4, 2022
    Hello Mick and welcome.

    I might be wide of the mark here, but some of the early triumphs had an eccentric rear hub. It could br rotated 180°, thus raising the ride height. Not sure it the sprint was one of them.

    • Agree Agree x 1
  6. David Cooper

    David Cooper Triumph Rocketeer.
    Subscriber

    Jun 23, 2018
    26,657
    1,000
    The Land of the Prince Bishops.
    #6 David Cooper, Jan 4, 2022
    Hello Mick

    gump (1).gif

    • Like Like x 1
  7. sprintdave

    sprintdave Nurse, think it's time for his medications.
    Subscriber

    May 25, 2014
    1,626
    750
    Birmingham
    #7 sprintdave, Jan 5, 2022
    Hi and welcome. As stated by johnbo, the rear axle is mounted on eccentric adjusters which rotate using 12 mm Allen keys, 1 each side preferably after loosening the clamp bolt at the end. If the Allen heads are below the axle the bike is at its high ride height, if above, the bike is low and you can rotate the adjusters 180 degrees to make it higher.
    Hope that makes sense.
    You may find the previous owner has lowered it as many do, myself included when I had my Sprint.

    • Agree Agree x 1
  8. Mick the marshman

    Mick the marshman New Member

    Nov 11, 2021
    4
    3
    Romney marsh kent
    #8 Mick the marshman, Jan 5, 2022
    Thank for info dave and johnbo it has a eccentric adjusters so easy option to do and see how the bike behaves, its currently in the low position

    • Like Like x 2
    • Agree Agree x 1
  9. Samsgrandad

    Samsgrandad Senior Member

    Dec 15, 2019
    648
    243
    Somerset
    #9 Samsgrandad, Jan 5, 2022
    Are you sure you need LONGER dog bones????
    They will lower the ride height, I think that you will need shorter dog bones to raise the ride height.

    • Agree Agree x 2
  10. Ducatitotriumph

    Ducatitotriumph Crème de la Crème

    Apr 25, 2019
    2,183
    1,000
    Rothwell
    #10 Ducatitotriumph, Jan 5, 2022
    Last edited: Jan 5, 2022
    Something like this?
    Worth a punt as you can adjust them + or -
    https://www.ebay.co.uk/itm/203740345059?hash=item2f6fdef2e3:g:x2AAAOSwc-Jhrfhx
    or
    https://www.ebay.co.uk/itm/283860511752?hash=item421767ac08:g:kk8AAOSwOYxchnsJ
    https://www.ebay.co.uk/itm/283860545822?hash=item421768311e:g:kk8AAOSwOYxchnsJ

    • Like Like x 1
  11. Smilinjack

    Smilinjack Guest

    #11 Smilinjack, Jan 5, 2022
    Welcome in mate. I thought at first glance we had some spam to contend with. "Hello, and would you rub my feet please" :grinning:

    • Funny Funny x 4
    • Agree Agree x 1
  12. Mrs Visor

    Mrs Visor Elite Member

    Aug 21, 2021
    3,611
    800
    UK
    #12 Mrs Visor, Jan 5, 2022
    I thought it was something nasty the likes of which I used to see working in A&E. "I just left it on a seat, forgot what I had done and sat on it, whilst not wearing any pants".....

    • Funny Funny x 3
    • Agree Agree x 1
  13. Mick the marshman

    Mick the marshman New Member

    Nov 11, 2021
    4
    3
    Romney marsh kent
    #13 Mick the marshman, Jan 6, 2022
    • Like Like x 1
    • Agree Agree x 1
  14. sprintdave

    sprintdave Nurse, think it's time for his medications.
    Subscriber

    May 25, 2014
    1,626
    750
    Birmingham
    #14 sprintdave, Jan 6, 2022
    If it is in the low position as you say, you will find the bike around 1 and a half to 2 inches higher at the back just using the eccentrics. If it is a mare to get on Centre stand that would probably confirm it.

    • Agree Agree x 2
  15. Dartplayer

    Dartplayer Crème de la Crème

    Aug 8, 2018
    7,540
    1,000
    New Zealand
    #15 Dartplayer, Jan 6, 2022
    Hi Mick and welcome to the forum :cool: good luck on your adjustment, looking forward to seeing your ride :p

  16. learningtofly

    learningtofly He’s not the Messiah, he’s a very naughty boy!
    Subscriber

    Sep 25, 2018
    2,172
    1,000
    Hertfordshire
    #16 learningtofly, Jan 10, 2022
    Welcome to the forum, Mick, but be careful with those thread titles :imp:
