Scrambler Dash Not Working - Scrambler 14 Efi

Discussion in 'Thruxton, Scrambler & Trident' started by TheHungryBadger, Jun 1, 2017.

  1. TheHungryBadger

    TheHungryBadger New Member

    Sep 16, 2016
    19
    3
    Chepstow
    Hi All,


    Looking for some help/advice, basically I put my Scrambler (2014 EFI) away on Friday evening, the engine was running and I noticed that nothing on the dash displace was working. I gave the bars a little wiggle and it all kicked back into life and lit up and resumed normal appearance. As I started to reposition the bike again, (to get close to the ground anchor) the dash died again yet the engine remained running.


    I parked it up and decided to try and find what might be the problem Saturday.


    Saturday morning came about after hardly any sleep (because I couldn’t stop thinking about the bike), put the key in the bike, headlight and tail light pop on, but nothing on the dash moved or lit up. Without the dash I can’t start the bike.

    I've checked:
    - battery
    - fuses
    - ignition

    So my question, has anyone had a similar issue or know what might be the problem?


    Thanks in advance,


    Regards,


    Badger

  2. Oldyam

    Oldyam Grumpy Old Git

    May 14, 2017
    610
    500
    ireland
    As @Dozers Dad says, I would suspect a broken wire / loose connection. Check the plug connecting the dash to the loom is pushed fully home.

    Also is there a cable tie holding the loom to the steering head, if there is and its tight cut the cable tie off and flex the loom at that point you'll probably find your broken wire ( common fault on beemers lol).

    If that's your fault you will need to cut into the loom and repair the faulty wire / wires.
    Replace any cable ties with another but fitted more loosely.

    • Like Like x 1
  3. Red Thunder

    Red Thunder Crème de la Crème

    Dec 2, 2014
    2,034
    1,000
    High Wycombe
    Bike wont start.png

    As said, wire near the headstock. Turn the bars and see what wires move, if any are particularly tight when the failure occurs then I would focus on there.

    • Like Like x 1
  4. TheHungryBadger

    TheHungryBadger New Member

    Sep 16, 2016
    19
    3
    Chepstow
    Ha, a friend at work sent that through to me Tuesday, but so true! Tinker time this evening, fingers crossed she will live again this weekend!
